Type: | Natural Gas Filter | Operating Temperature: | -40~300℃ |
---|---|---|---|
Operating Pressure: | 0.1~40Mpa | Seperate Accuracy: | 0.1/1/2/3/5/10um |
Separate Efficiency: | 99.98% | Installation: | Vertical Or Horizontal |
Highlight: | dry gas filter,natural gas filter separator |
Standard Natural Gas Filter For Gas-Solid Separation
Description:
U- TC - B series standard natural gas filter is mainly used for gas-solid separation. Equipped with 5 ~ 300 micron stainless steel folded filter element, it has advantages including big filtration area, small pressure loss and dirt carrying capacity, and can effectively remove impurity particles in natural gas.
Technical features:
Pressure of work: 0.1 ~ 40.0 Mpa
Working temperature: - 30 ~ 300 ℃
Applicable medium: natural gas, the artificial coal gas and liquefied petroleum gas, oil associated gas, etc
Manufacturing standards: GB150, ASME
The filter installation: vertical, horizontal
Import and export of installation direction: horizontal and vertical
Shell material:
20#,16Mn,16MnR,16MnDR,304,316L
Filter:
Filter material: metal folding type, fiber folding type
Filtration precision: 5 microns to 300 microns
Filtration efficiency: more than 99%
Model | TC-B-0.5 | TC-B-1.0 | TC-B-1.5 | TC-B-2.0 | TC-B-2.5 | TC-B-3.0 |
Filter element | G0.5 | G1.0 | G1.5 | G2.0 | G2.5 | G3 |
Element qty | 1 | 1 | 1 | 1 | 1 | 1 |
Weight(kg) | 30 | 30 | 42 | 60 | 85 | 115 |
Volume(L) | 3 | 5 | 10 | 20 | 40 | 60 |
Chamber volume(L) | 1 | 1.2 | 2 | 5 | 8 | 14 |
A(mm) | 368 | 443 | 528 | 642 | 744 | 852 |
B(mm) | 156 | 178 | 207 | 233 | 271 | 310 |
D(mm) | 114 | 133 | 168 | 273 | 273 | 325 |
L(mm) | 150 | 200 | 225 | 250 | 300 | 325 |
