Product Description
Easy operate high-pressure air 983 resin dispensing glue machine
High Precision Semi-auto Glue Dispensing Machine is using pedal switch making liquid out by high pressure in setting period . 2. it can be adjusted flexibly for the manual, semi-automatic. We have use high-precision digital controller to control dripping time accurately even millisecond . so it can control liquid flux to avoid wasting. 3. As long as pressure, time and right needle, it is easy to change the dripping quantity and dripping time. This machine could solve many problems ,it is easy and fast for operation with vacuum suction function to control different viscous liquid to prevent the leakage. 4. high efficiency,easy fatigue, no waste, wide using , we have complete product,we can provide different types of syringes, needles according to user’s need.Parameters.
Suitable Liquid:All kinds of solvent, adhesive, paint, chemical materials, solid glue, etc., including the silica gel, the EMI conductive adhesive, UV glue, AB glue, fast dry glue, epoxy adhesive, sealant, hot glue, grease, silver glue, red glue, solder paste, cooling paste, prevent solder paste, transparent lacquer, screw fixation agent, wood glue, anaerobic adhesive, acrylic rubber, wear rubber, resin, filling glue, horn glue, super glue, rubber, paint, enamel paint, bright paint, printing ink, paint, etc.
1, Digital display dispensing time and space time, very clearly.
2, Standard configuration,, Vacuum structure to prevent Drooling .
3, Many models of liquid dropping function, High efficiency.
4, Widely applicable pressure range, can suit Various viscosity liquids .
5, Will be very easy to debug, having debugging switch .
6, With perfect liquid dropping signal terminal functions can be used with robot use .
| Model |
Vs-983 |
| Control |
Electronic pneumatic |
| Dispensing function mode |
Automatic/foot |
| Dispensing pressure |
0.05-0.6 Mpa |
| Dispensing time |
0-82s |
| Vacuum pressure |
0-20Kpa |
| Special features |
vacuum suction function |
| Power |
AC220-240V, 50Hz,15W |
| Dimensions |
230mm*150mm*53mm |
| Weight |
2.5kg
|
Characteristic:
Exquisite pedal switch , It has two kinds of operation laws:
1. Operate (auto) automatically (are suitable for ration, some glue of non- timing)
Transfer the switch to automatic auto seat.
Adjust the atmospheric pressure and produce glue amount, can control the correct flow of the material of liquid to choose when being chewed with needle suitable.
Step on once pedal switch, liquid material can automatic to drip, produce from pinpoint hole according to amount of glue appeared that establish.
2. Operate (manual) with hands (it suitable fors to be ration, non- timing some glue)
Transfer the switch in the position to manual.
Adjust the atmospheric pressure and choose the needle suitable to chew.
Step on the pedal switch, the material of liquid will be dripped from pinpoint hole out, unclamp the liquid material of pedal switch and stop dripping out.
Suitable Liquid:
All kinds of solvent, adhesive, paint, chemical materials, solid glue, etc., including the silica gel, the EMI conductive adhesive, UV glue, AB glue, fast dry glue, epoxy adhesive, sealant, hot glue, grease, silver glue, red glue, solder paste, cooling paste, prevent solder paste, transparent lacquer, screw fixation agent, wood glue, anaerobic adhesive, acrylic rubber, wear rubber, resin, filling glue, horn glue, super glue, rubber, paint, enamel paint, bright paint, printing ink, paint, etc.
Applicable liquid material:
Continue pharmaceutical, the oil of damping, add the oxygen glue of ring, there is no glue of oxygen, Chemical reagent, help the solder flux, copper solder flux, organic colloidal silica, Glue pharmaceutical, leading, colloidal silica, oil, The solidifying type covers pharmaceutical, hinder the solder flux, printing ink, paint, Tin thick liquid, fibrous paint, the drip, the solvent.
