2W (Large Orifice )
Two Position Two Way Solenoid Valve
Various Material for your choose ,Reasonable Design ,Reliable Quality
1.Direct Acting ,Diaphragm Structure ,can be work at zero pressure ,Expanding hte using area
2.Plate diaphragm structure ,high reliablity ,long life
3.Valve body can be made from brass ,stainless steel
4.Plastic encapsulating coil ,be able to use under numerous enviroment.
Media : Air ,Water ,Oil
Working Type : Direct Action
Pattern : Normally Close
Orifice : 40 mm
Cv Value :29
Connection Ports : G1-1/2''
Fluid Viscosity : < 20CST
Working Pressure : Air : 0~1 Mpa ,Water ,Oil : 0-0.7Mpa
Max Pressure :1 Mpa
Working Temp :-5 ~ 80°
Rated Voltage : DC12-24 V ,AC24-380V
Power :DC 23.4 W ,AC26VA
Valve Body Material :Stainless Steel
Seal Material :NBR ,EPDM ,VITON
Our goods have been sold to the USA, Germany, Holand, Italy, France, Korea and other countries and regions. Our products, liquid valves, liquid gas check valve, liquid line solenoid valve, liquid relief valve, liquid crystal light valve, liquid solenoid valve, liquid level control valve, liquid flow control valve, liquid pressure relief valve,liquid nitrogen valve, liquid withdrawal valve, liquid injection valve, liquid line service valve, liquid propane valve, liquid dispensing valve, liquid sampling valve are produced according to the ISO9001:2000 standards. We hope that we will be your best partner in china. More information .Pls kindly free to contact with us .
