Wire mesh screen PLC Auto Back Flushing Filter with CE certificate

Large Image : Wire mesh screen PLC Auto Back Flushing Filter with CE certificate

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	UNITE
Certification:	ASME, ISO, ABS
Model Number:	U-ZC-SF-500

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Export Wooden Case
Delivery Time:	10-50 days
Payment Terms:	T/T, L/C
Supply Ability:	500 Sets / Month

Contact Now

Detailed Product Description

Material:	304, 316L	Filtration Micro Rating:	Can Reach 0.5um
Filter Area:	2.4m2	Temperature:	0-80℃
Filter Element:	316L Power Sintered	Type:	Automatic Operate
Highlight:	automatic backflush filter , back flush filter

Automatic Back Washing Filter for Lens Cutting Water with 0.5um high precision

Automatic washing filter is a multifunctional automatic backwashing filtration system, using for separating solid particle from liquid or gas. We adopt high precision filter tubes which are combined into filter internals and put into tube vessels. Such vessel is designed and manufactured according to GB150 and also supervised by Pressure Vessel Safety And Technology Supervision Regulation.

Specification:

MODEL:U—ZC-SF-500
FLUID:Lens Cutting Water
FLOW RATE:2t/h
PERATING TEMPERATURE:normal temperature
DESIGN TEMPERATURE:80℃
OPERATING PRESSURE:O.4Mpa
DESIGN PRESSURE:0.5Mpa
SIZE OF FILTRATIOⅣ:0.5um
EREA OF FILTRATIOⅣ:2.4m²
HEAD& SHELL:304
INTERNALS/ ELEMENT:304
STAY-BOLT:304
FILTER ELEMENT:316L power sintered

Applications:
1. Feedstock oil backwashing filter technology in petro chemical hydrogenation plant
2. Removal of sulphur, ammonia and metal impurities from the oil during refine of the oil
3. Catalysis oil slurry automatic backwashing filter system
4. Desulfurization system amine circulation purification technology
5. Filter amine solution in chemical gas desulfurization systems
6. Acetic acid filtration and purification technology
7. Removal of carbon particle in acetic acid, vinyl acetate, acetaldehyde in the production of vinyl acetate
8. Water filtration and purification technology
9. The dealt of oily wastewater, corrosive water, medicine and chemical sewage
10. Integrated coal gasification and liquefaction filtration technology
11. For gas and liquid filtration in coal gasification and liquefaction
12. High concentrations of materials proprietary filtering technology
13. Synthesizing means synthetic oil filter
14. High temperature and high pressure gas pulse cleaning Regeneration
