Industrial Concrete Mixing Plant 1200KG High Power stirring mill Slurry Metering Power of machine 140KW - 200KW
Description:
Concrete mixing equipment series, our equipment can produce dry and hard plastic concrete is used.Our company has many years of production experience. Consumers across the country.
Technical Parameter:
|
Item |
Parameter |
||||
|
Model |
HLS60 |
HLS90 |
HLS120 |
HLS180 |
|
|
Max.productivity |
60 m3/h |
90 m3/h |
120 m3/h |
180 m3/h |
|
|
Matching stirring mill |
JS1000 |
JS1500 |
JS2000 |
JS3000 |
|
|
Reclaiming capacity |
1000L |
1500L |
2000L |
3000 L |
|
|
Charging capacity |
1600L |
2400L |
3200L |
4800 L |
|
|
Max measuring value of aggregate |
2000 kg |
1500 kg |
2000 kg |
3000 kg |
|
|
Max measuring value of cement |
500 kg |
900 kg |
1200KG |
1600 kg |
|
|
Max measuring value of fly ash |
200 kg |
450 kg |
600KG |
800 kg |
|
|
Max measuring value of water |
200 kg |
450 kg |
600KG |
1000 kg |
|
|
Max measuring value of liquid additive |
20 kg |
50 kg |
50KG |
50 kg |
|
|
Power of mixer |
18.5kW |
30kW |
37kW |
55 kW |
|
|
Power of machine |
140KW |
160KW |
200KW |
200 kW |
|
|
Discharge height |
3.8m |
3.8m |
3.8m |
3.85 m |
|
|
Measure precision |
Aggregate |
± 2 % |
|||
|
Water |
± 1 % |
||||
|
Cement fly ash |
± 1 % |
||||
|
Additive |
± 2% |
||||
Technical parameter
a) Max geometric size:: diameter: φ1750 mm, H≈2250 mm
b) Mass: 709 kg
c) Weight: 3000 kg
d) Model of loading sensor: “3410”
e) Pneumatic butterfly valve: D671J-10-125
Competitive Advantage:
1. Adopting twin forced horizontal shafts stirrer
2. The aggregate is measured alone or accumulated by the electronic scale.
3. Water and the additive are measured accurately under the centralized control of
the computer.
4. The whole machine adopts PC to control, which is easy to operate and debug.
5. Two models for feeding aggregate: one by bucket elevator, the other by belt transfer.
6. The main electric elements are the devices of Schneider in France; the programmable
controller is the product of Siemens.
About us :
Changzhou Success Building Material Machinery Co., Ltd., hereinaftercalled “Success”, is the professional enterprise for fabrication of new style building material machinery and equipment. With the total investment of more than 20 million yuan and in the area of 30,000 suqre meter being occupied, there are various kinds of medium-scale and large-scale fabrication facilities in Success. There are three strong teams in Success, namely, the skilled worker team in rich experience of more than 30 years, the techinical research and development team, as well as the management team. College graduates occupies 60% of the entire management-related personnel. Success has already established the long-term cooperation relationship with the domestic well-known universities and colleges and famous engineering experts in the field of building material in China.
