*The popular robot in FD series robots
*Dispensing Area 200 X 200 X 100 ,300 X 300 X 100 and 400x400x100 mm
*Dot, Lines, Arc etc. and 3D dispensing path is available.
*100 programs, 4000 points per program
*A hand-held Teach Pendant is provided for simple and intuitive programming functions
*SRE software is available for CAD file input (optional)
*Apply adhesives, cyanoacrylates, silicone, RTV, anaerobic resin, epoxy, UV cure formulations and many more fluids.
*Every robot will be with one small dispenser controller TS9150,tips barrels etc as full unit
|Working Range X/Y/Z(mm)||200/200/50||300/300/100||400/400/100||500*500*100|
|Load Y-AXIS / Z-AXIS||5 kg / 3 kg||10 kg / 5 kg|
|X&Y / Z (mm/sec)||0.1-500/250||0.1-600/300|
|Repetitive Positioning Accuracy||+/- 0.01 mm/ Axis|
|Program Capacity||100 Programs、4000 points/program|
|Program Display||Teach Pendant LCD|
|Motor System||Micro stepping motor|
|Control Method||PTP & CP|
|Interpolation Function||3 axis ( 3D )|
|Programming Method||Teach Pendant|
|I/O Signals Port||8 Inputs / 8 Outputs|
|External Control Interface||RS232|
|Power Supply||AC110 ~ 220V 300W|
|Working Temperature||10 - 40 'C|
|Working Relative Humidity||20 - 90% no condensation|
|Dimensions (WxDxH mm)||385 x 370 x 500||485 x 500 x 600||585 x 600 x 600||685 x 700 x 600|
|Robot Weight (kg)||23 kg||32 kg||40 kg||45 kg|
FD Dispenser CO.,LTD is a Top leading dispenser manufacturer in the global market. the products line include dispenser,robot dispenser.dispenser tips,barrels adapter.valve.pressure tank,mixer tube and speicialized dispenser accessories as every customer demand. we have very good global marketing net and self shipment way to bridge with all the customers as neighbor.
From Establish of the dispenser supplier in 2007. all the FD staff alway in the standar of the customer solution. Quality controll and Credit service are basic rule and the life for every person of FD Dispenser company.to progress and make good brand of FD is the aim forever.
